07KT97 GJR5253000R0270 ABB  controller module

The relays must operate from the lowest value onwards but may operate earlier. The release must take place at the latest when the value falls to 5 % (for DC current/voltage) or 15 % (for AC current/ voltage) of the rated value.

Relevant for this are the specified operate value ΘOP of the system and the specified release value ΘRL of the system. These values limit the operating range. A further limit is given by the maximum permissible heating. The coil resistance is stated as nominal value at 20 °C (with the permissible tolerance). If heating to above 20 °C, the coil resistance is increased by 0.38 %/K; if cooling to below 20 °C, the coil resistance is increased by 0.38 %/K.For an energizing quantity 'current' this means: The permissible operating range is constant for the entire temperature range.

For an energizing quantity 'voltage' this means: For higher coil temperatures, a higher voltage is needed to reach or exceed the operate sensitivity. For lower coil temperatures, a lower voltage is needed to reach or fall below the release value.

Compared with the preferential temperature range of -5...40 °C the following holds for temperatures outside this range: If extending from, for example, -5 °C...-25 °C, the maximum permissible voltage decreases since at lower temperatures the voltage only reaches or falls below the release value at lower voltages.

If extending from, for example, 40 °C...70 °C, the minimum permissible voltage increases since at higher temperatures the voltage only reaches or exceeds the operate value at higher voltages. At the same time, the maximum permissible voltage decreases since at higher temperatures the maximum permissible power loss (and thus the maximum permissible voltage) are lower.

The structure and details of the product：

Please make an inquiry for more models
