1TGE102009R4800  ABB  Analog Input Module

The instrument has an internal Webserver to make some of the display and configuration pages available for the user. The Webserver makes available a virtual instrument on the remote user PC. It is possible to access the instrument by using any Browser (Internet Explorer, Mozilla Firefox, etc.) and typing http://instrument -IP-address or http://instrument-hostname. The first page that is displayed after the access to the instrument is the ANALYSER MENU, where you can navigate the instrument in the same way used for field navigation.

Following the order presented in the visualization above, the parameters in the table represent: • Rated voltages; • Linked voltages; • Currents; • Active power; • Reactive power; • Apparent power; • Partial energy balance; • Total energy balance;

The total energy balance represents the difference between absorbed and generated energy, whereas the partial energy balance represents the difference between absorbed and generated power during a lapse of time defined by the user on the field instrument. If the measurement function on four quadrants is not active and the instrument is set for measuring only absorbed or consumed energy, partial and total energy balances represent the produced or consumed energy only

The ANALYSER and TABLE menus are menus for the access to the display of electric parameters measured on the field by M2M. The access to these two pages is possible through a connection via browser in the ways described in chapter 2. The access to MODBUS TCP, LANGUAGE and NETWORK menus is protected by authentication with User name and Password since they allow to access configuration pages. Selecting the AUTHENTICATION MENU it is possible to display the page for the modification of Password and User name.
