ACM12 YOKOGAWA Controller module

Upgrade Note

When upgrading to the latest version, it is advisable to upgrade the panel first, and then upgrade the ACM12 module

Off-Line Feature

The ACM12 V4.5 and higher fully supports Off-Line functionality. In the case of panel connection loss, the ACM12 will switch to Off-Line mode and will fully function with user access level and schedules; arm / disarm user permissions will be overridden. While resuming communications with the panel, all programming changes will be updated. In Off-Line mode, events are kept locally in the module and can be uploaded manually for each ACM12 when communication is restored.

Installation (Figure 1)

Connect the ACM12 as per the drawing below. When powering up, all ACM12 modules will synchronize with the panel and upload all user and schedule data. Typically, 100 users and 10 schedules will take about 50 seconds to upload. This will also take place upon resuming connection with the panel. Synchronization is indicated by RX/TX LEDs flashing together at 4 Hz. If an ACM12 V4.5 detects a connection to a different EVO panel, data will be erased and the new panel data will be synchronized.

Changing the Default Reader Assignment (V4.52 and above)

1. Press and hold the AUX ON / OFF switch for 3 seconds. The ERROR, TX and RX LEDs flash for 2-3 seconds.
2. 2. Press any key or present an access card to the reader you want to designate as the IN reader. Automatically, the other reader will be designated as the OUT reader.
