AF16-30-10-13 1SBL177001R1310  ABB  Analog Output Modules

Here it is possible to visualize the measurements, through a speedometer graph, phasor chart, bar graph and trend line chart. Moreover, in the lower part of the screen, sample time for data export is shown and can be modified.After entering the sampling time value, click on Historical and select the folder where you want to save the .csv file with measured data. M2M SW will start saving in the .csv file the measurements according to the sampling time. To stop the data export, click again on Historical.

Clicking on Data reading via Modbus map 1, Data reading via Modbus map 2, Data reading via Modbus map 3 allows to visualize and export measurement data under Modbus map form. The three Modbus tables differentiate each other according to the data format: - Data reading via Modbus map 1: float 32 bits - Data reading via Modbus map 2: integer 32 bits - Data reading via Modbus map 3: integer 16 bits. It is possible to export measured data in the same way as per the Data reading section.

Clicking on Configure meter, the following window will appear on the screen: Here the software allows setting all the configuration parameters that can be also modified through the device. Clicking on Communication,

If a VT is installed: verify that the secondary phase voltage falls in the range between 40 V and 300 V A.C. and that the secondary line voltage falls in the range between 69 V and 515 V A.C.; verify that the real phase voltage (primary phase voltage) falls in the range between 40 V and 800,000 V A.C

The structure and details of the product：

Please make an inquiry for more models
