DSQC506 3HAC4297-1  ABB  Basis unit

RED615 is available in two alternative standard configurations. The standard signal configuration can be altered by means of the signal matrix or the graphical application functionality of the Protection and Control Relay Manager PCM600. Further, the application configuration functionality of PCM600 supports the creation of multi-layer logic functions utilizing various logical elements including timers and flip-flops. By combining protection functions with logic function blocks the relay configuration can be adapted to user specific application requirements.

The relay is delivered from the factory with default connections described in the functional diagrams for binary inputs, binary outputs, function-tofunction connections and alarm LEDs. Some of the supported functions in RED615 must be added with the Application Configuration tool to be available in the Signal Matrix tool and in the relay. The positive measuring direction of directional protection functions is towards the outgoing feeder.

The relay offers two-stage phase-segregated line differential protection, phase overcurrent protection, negative-sequence overcurrent protection and circuit breaker failure protection. Depending on the chosen standard configuration, the basic functionality can be extended by thermal overload protection, non-directional or directional overcurrent protection, directional or nondirectional ground-fault protection, sensitive ground-fault protection, phase discontinuity protection, transient/intermittent ground-fault protection, residual overvoltage protection, phasevoltage and frequency based protection and threepole multi-shot auto-reclosing functions for overhead line feeders. For standard configurations B, D and E, admittance-based, watt-metric-based or harmonics-based ground-fault protection is offered as an option in addition to the directional ground-fault protection.

The structure and details of the product：

Please make an inquiry for more models
