Azipod is an electric azimuthing propulsion system. The electric motor is inside a submerged pod. Propulsion module with speed controlled fixed pitch propeller can be rotated 360 degrees around its vertical axis. The system offers high efficiency with excellent maneuverability.

Azipod Propulsion and Steering

The Azipod XO2100 and XO2300 are the successors to the classic “V21” and “V23” series Azipod products. Azipod propulsion is designed for the preferential use of the (directly driven) pulling propeller when driving in the ahead direction. The type XO2100 and XO2300 Azipod propulsion units are available generally for power ratings of between 13 - 18 MW and 18 – 23 MW respectively. The power rating is depending on the propeller design.

The full ship system consists of the required number of Azipod steering propulsors, plus the delivery of an PWM type marine Propulsion Power Drive per each Azipod. Additionally, propulsion supply transformers (if needed), a remote control system, and the power plant (generators, switchboards and transformers) are usually included in the scope of the delivery.

In order to drive the Azipod propulsion system, the ship needs an electric power plant (not specifically discussed in this document). Generator sets supply power to the 50 or 60 Hz installation of electric switchboards for distribution to all consumers onboard, including Azipod propulsion.

Generally, ABB aims to deliver the power plant as well as the Azipod system. Our mechanical interface to the engine maker is basically standard, although dependent on the delivery of engines or e.g. gas turbines from the contractors.

During the whole project, the basic tool for power plant design is the so-called single-line diagram. The actual onboard configuration can be efficiently discussed already in the early stages of work by using this clear visual representation.

The structure and details of the product：
