Siemens 6ES7972-0DA00-0AA0  I/O module

SIMATIC DP, RS485 terminating resistor for terminating PROFIBUS/MPI networks

24 V power supply LED

Connection for 24 V DC power supply

PROFIBUS connection Shield clip for grounding the braided screen and for strain relief on the bus cable

Grounding screw

Shield clip for strain relief on the power supply cable

Stripping the insulation from the cable and turning back the braided screen with the following:

SIMATIC NET PROFIBUS cable (order no. 6XV1 830-0AH10, 6XV1 830-3BH10) as in figure IIa

SIMATIC NET PROFIBUS cable (order no. 6XV1 830-3AH10) as in figure IIb

Connecting the cables to the PROFIBUS terminator

PROFIBUS connection The cable shield must lie bare on the metal guide

Power supply connection

Ground connection

Note

Ensure during setup that there is no terminating resistor connected to the PROFIBUS-DP connectors if the PROFIBUS is set up with 2 active PROFIBUS terminators.

The structure and details of the product：
