Siemens TXA1.IBE Processor module

The island bus expansion modules allow for “decentralized” sub-islands with TX-I/O-modules, that may be located up to 2 x 200 m from the "local" sub-island.

A programming / parameterization tool is not required.

The DIP switches for the bus master and bus terminator must be set correctly on the island bus expansion modules.

The island bus expansion is based on differential RS-485 transmission technology.

 "Decentralized" sub-island can be supplied using a separate power supply. Loss of this power does not impact the island bus of local sub-islands. For details on wiring and topology, refer to TX-I/O™ engineering and installation manual, CM110562.

Full functionality is only possible using

TX-I/O modules from series C and higher

P-bus interface modules series B and higher

PXC-NRUD Series C and higher only (Migration – INTEGRAL AS1000)

All models of PROFINET BIM Functionality is reduced when using modules for series B and BIM series A: refer to CM110562.

Mechanical properties

The housing complies with DIN 43880 and is 32mm wide.

The island bus expansion module is plugged on the right side of the power module / bus connection module on the standard rail. The electrical connection is on the 4 side island bus contacts. The bus establishes its own connection, when TX-I/O™ devices are plugged into one another on the rails.

Disposal

The devices are considered electronics devices for disposal in terms of European Directive 2012/19/EU and may not be disposed of as domestic garbage.

Dispose of the devices through channels provided for this purpose.

Comply with all local and currently applicable laws and regulations.

The structure and details of the product：
