1606-XL120DR A-B  Digital Input Module

Control Wiring • The control logic is 24V DC and can be set for either Sink or Source control via a DIP switch setting. • Control terminal screws are sized for a conventional blade screwdriver. • I/O Terminals 1, 2, and 3 are dedicated for Stop, Start, and Reverse operation respectively. These I/O Terminals can be programmed for 2-wire or 3-wire operation to meet application requirements. • I/O Terminals 4 and 5 are programmable and provide added flexibility. Programmable functions include: - Local Control - Preset Frequencies - Jog - RS-485 Control - Second Accel/Decel - Auxiliary Fault - Clear Fault • Speed can be controlled via a 0…10V input or 4…20 mA input. Both are electrically isolated from the drive. • One form C relay can be programmed to provide the status of a wide variety of drive conditions. The drive is shipped with a jumper installed between I/O Terminals 01 and 02…11 to allow out of box operation from the keypad.

ATTENTION: This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR 11. Without appropriate precautions, there may be difficulties with electromagnetic compatibility in residential and other environments due to conducted and radiated disturbances. This equipment is supplied as open-type equipment. It must be mounted within an enclosure that is suitably designed for those specific environmental conditions that will be present and appropriately designed to prevent personal injury resulting from accessibility to live parts. The enclosure must have suitable flame-retardant properties to prevent or minimize the spread of flame, complying with a flame spread rating of 5VA or be approved for the application if nonmetallic. The interior of the enclosure must be accessible only by the use of a tool. Subsequent sections of this publication may contain additional information regarding specific enclosure type ratings that are required to comply with certain product safety certifications.

The structure and details of the product：

Please make an inquiry for more models
